Blaze AC 22kW

Name: Blaze AC 22kW
Brand: Default Vendor
SKU: 5011100076
Price: 59999.00 INR
Availability: InStock

4-Wheeler Chargers

High-speed AC charger ideal for residential, or business settings for public and commercial use

Power Rating:

22kW

Compatibility:

Connector type:

Type 2 AC

Common brands compatible with this product:

This charger is compatible with all 4 wheelers

₹59,999.00

Quantity

View full details

Dimensions

(Fits on Wall & Stand Mount)

Certifications

ARAI Certified

Embrace the next generation of EV charging with Bolt.Earth Blaze AC.

Can’t find the right AC fast charger for your electric vehicle? Look no further than the Bolt.Earth Blaze AC! This powerful charger delivers a 22kW output, significantly reducing your charging time compared to a Level 1 charger.

Stay informed about your charging status with an intuitive charger status and energy display, providing real-time updates on your charging progress. Built to withstand harsh weather, Blaze AC is water resistant and comes equipped with a gun holder for added safety and convenience. Considering EV fast charging stations for your home? The Blaze AC offers versatility and reliability for all your charging needs and is compatible with a wide range of EVs.

Output Power Rating:

22kW

Input Voltage:

Three Phase 400V±10%

Output Voltage:

400V

Maximum Output Current:

32A

Dynamic Load Balancer:

Yes

Rated Frequency:

50Hz

Charger Connector Type:

Type 2 AC Connector (IEC 62196-2)

Connectivity:

Wi-Fi, 4G (Optional), Ethernet (Optional)

Charge Installation Type:

Wall Mount or Stand Mount

Dimension:

400mm * 250mm * 125mm

Weight:

6kg

Weather Protection:

IP 56

OTA Support:

Yes

User Authentication:

QR code, Plug & Charge, RFID

Suggested Usage Type:

Home / Personal use / Public

Interoperability:

Supports OCPP 1.6J

Charging Progress Indication:

LED pattern

Warranty:

1 year Warranty Guide

Protection and Safety:

Auto Power Cut-Off, Power Theft Protection, Inbuilt Energy Measurement, Over & Under Voltage Protection, Charger Over temperature Protection, Emergency Push Button, Type B Earth Leakage Protection

Embrace the next generation of EV charging with Bolt.Earth Blaze AC.

Can’t find the right AC fast charger for your electric vehicle? Look no further than the Bolt.Earth Blaze AC! This powerful charger delivers a 22kW output, significantly reducing your charging time compared to a Level 1 charger.

Stay informed about your charging status with an intuitive charger status and energy display, providing real-time updates on your charging progress. Built to withstand harsh weather, Blaze AC is water resistant and comes equipped with a gun holder for added safety and convenience. Considering EV fast charging stations for your home? The Blaze AC offers versatility and reliability for all your charging needs and is compatible with a wide range of EVs.

Output Power Rating:

22kW

Input Voltage:

Three Phase 400V±10%

Output Voltage:

400V

Maximum Output Current:

32A

Dynamic Load Balancer:

Yes

Rated Frequency:

50Hz

Charger Connector Type:

Type 2 AC Connector (IEC 62196-2)

Connectivity:

Wi-Fi, 4G (Optional), Ethernet (Optional)

Charge Installation Type:

Wall Mount or Stand Mount

Dimension:

400mm * 250mm * 125mm

Weight:

6kg

Weather Protection:

IP 56

OTA Support:

Yes

User Authentication:

QR code, Plug & Charge, RFID

Suggested Usage Type:

Home / Personal use / Public

Interoperability:

Supports OCPP 1.6J

Charging Progress Indication:

LED pattern

Warranty:

1 year Warranty Guide

Protection and Safety:

Auto Power Cut-Off, Power Theft Protection, Inbuilt Energy Measurement, Over & Under Voltage Protection, Charger Over temperature Protection, Emergency Push Button, Type B Earth Leakage Protection
